AG 280 BDE

Adjustable aluminium slot diffusers with adjustable diffusion using two directional deflectors on each slot.

Used for air supply and air exhaust in heating & air-conditioning installations. Available in various shapes according to the structural requirements of building. Ceiling and wall mounted.

Description.

AG 200 series: available in slots of 20 mm, 25 mm and 12.5 mm, from 1 to 8 slots.
For continuous length assembly, the maximum length per section will be 3000 mm complete with alignment strips.
Two air pattern deflectors per slot provide an adjustable air pattern of 180°fully. The hit-and-miss damper does not affect the air pattern and can be used as an equalizing grid.
Flange less option available upon customer request
